Drive Unit
|
Yamaha, PW-ST System, 250 Wh, 70 Nm, 25 km/h
|
|
Display
|
Yamaha, Side Switch, 1.7" LCD, 7 functions
|
|
Battery
|
Yamaha, InTube, 630 Wh
|
|
Frame Family
|
Haibike, Aluminium 6061, Yamaha InTube 630, HD Interface, Aluminium 6061
|
|
Fork
|
SR Suntour, NEX E25-HLO, Lockout, Steel spring, 63 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
|
|
Crank Arm
|
Haibike, Forged, Aluminium
|
|
Brake (Front)
|
Alhonga, HT474, Hydraulic disc brakes
|
|
Brake (Rear)
|
Alhonga, HT474, Hydraulic disc brakes
|
|
Tube
|
Dunlop valve
|
|
Rim
|
Schürmann, Yak25, With Eyelets, Double Wall, Aluminium
|
|
Clamping Ring
|
quick release, Quick release, 34.9 mm
|
|
Rear Derailleur
|
Shimano, Deore M4120
|
|
Shift Lever
|
Shimano, Deore M4100, Trigger switch
|
|
Bottom Bracket
|
integrated in the motor
|
|
Sprocket
|
Shimano, CSM4100, 11 - 42 teeth
|
|
Chain
|
KMC, e10S
|
|
Chainring
|
Steel, 38 teeth
|
|
Brake Lever
|
Alhonga, HT474, Aluminium
|
|
Brake Disc (Front)
|
Alhonga, DXR1806, 180 mm
|
|
Brake Disc (Rear)
|
Alhonga, DXR1806, 180 mm
|
|
Tyre
|
Schwalbe, Al Grounder Performance, 60-584, 27.5 x 2.4 inch
|
|
Front Wheel Hub
|
alu hub
|
|
Rear Wheel Hub
|
Alu Nabe, 6-bolt standard
|
|
Spokes
|
Sapim, Leader
|
|
Handlebar
|
XLC, Topflat, 720 mm
|
|
Grips
|
XLC, Comfort bo3
|
|
Stem
|
XLC, Alu, A-head
|
|
Headset
|
Feimin, A-Head Tapered, Ball bearingCane Creek, Viscoset, Aluminium
|
|
Saddle
|
XLC, Trekking
|
|
Seat Post
|
XLC, Aluminium, Patent, 31.6 mm
|
|
Pedals
|
VP, E461, Aluminium, with Reflector
|
|
Headlight
|
Haibike, Skybeamer 150, 50 lm
|
|
Rear Light
|
AXA, Juno Ebike
|
|
Dynamo
|
via system battery
|
|
Carrier
|
Massload, Systemgepäckträger
|
|
Fenders
|
Eurofender, Tempo, ChromoplasticsSKS, Chromoplastics
|
|
Stand
|
Ursus, Mooi, Rear stand
|
|
Permitted Total Weight
|
130.0 kg
|
